Kaba Simplex 6200

Kaba Simplex 6200

SKU:
6200
$295.00
(No reviews yet)
Weight:
4.00 LBS
Width:
0.10 (in)
Height:
0.10 (in)
Depth:
0.10 (in)
Current Stock:
Adding to cart… The item has been added
Description

Overview:

Simplex 6000 provides fully mechanical exterior access by combination, while allowing free egress at all times by interior knob. This fully mechanical lock eliminates the material and labor expense of battery replacements, has a single access-code and is programmed via the keypad without removing the lock from the door.

Features:

No Battery: Fully mechanical lock eliminates the material and labor expense of battery replacements

Locking Device: Cylindrical latch with 3-hour UL/ULC fire rating for "A" labeled doors

Number of Codes: Single access code—one easy-to-manage code for all users

Programming: Lock is easily programmed via keypad without removing lock from the door

Handing: Factory-handed left; easily field reversible

Operation Mode: Pushbutton access

Economical: A cost effective access control solution

Techinical Data:

Construction: All metal cast front housing, force-resistant, clutch-protected exterior thumbturn, unified interior trim plate, fixed interior knob

Numeric Keypad: Vandal resistant, solid metal pushbuttons

Handing: Factory-handed left; easily field reversible

Finishes: Hard, durable powder paint finishes –

  • Gold Tone (060)

    Simplex Gold Vein Finish - 060

  • Almond (067)

    Simplex Almond Finish - 67


    • Gold and Almond inside trim/plated Bright Brass
  • Black (085)

  • Gray (086)

    Simplex Grey Finish - 86

    • Black and Gray inside trim/plated Satin Chrome

Latch: ½" (13 mm) throw latch, floating faceplate (UL listed)

Backset: 2¾" (70 mm) or 2⅜" (60 mm) backset

Minimum Stile Recommended: 5" (127 mm)

Weight: 4.5 lbs. (2 kg)

Strike: Standard strike plate

Installation: ASA 161 door preparation with two additional through bore holes. Lock can be inverted if the existing auxiliary lock obstructs installation.

Door Thickness: 1⅜" (35 mm) to 2¼" (57 mm); wood or metal

Items Supplied Include: Installation manual, full-scale template, combination change tool, and required installation hardware
